Music LED Controller Dynamic Audio Lights Controller

Description:

1. 8-channel output signal (data-independent). Apply to large project and long distance transmission. Support several controllers cascade using.

2. Control variety of regular chips in LED digital tube screen, LED pixel light screen, and etc.

SW Single chip: D**S, D**J.

Single-wire: TM180*-400K/800K, UCS19**, UCS29**, WS2811/12, TLS3001(1Mhz), SM167**.

DMX512: SW-D, SW-U, UCS512A/B/C0/C4/D/E0/EH, DMX512AP/SM512, SM16500P, SM16511/12, SM17500P/12P/22P, SM17512/22, Hi512A0, Hi512A4, Hi512A6, TM512AB3, TM512AL1, TM512ACx, TM512AD, QED512P, standard DMX512 lighting fixture on the market.

Breakpoint resume: UCS5603, WS2818, GS8206, P9883, TM1914, XT1506S, GS8512.

3. Audio control, sound control, cascade sync, time control, GPS satellite sync and BTS satellite sync are optional as additional functions.

4. Specialized software of making animation is included, user can make their own effects.

5. The load capacity of different lighting fixtures is different. (If no specific requirement of frame frequency, load capacity of each channel can be increased independently, and user must conduct the test by himself/herself.)
